Model | H4T | H6T | H8T | H10T |
Input data | ||||
PV array input numbers | 4 | 6 | 8 | 10 |
Max single PV array current | 16A | |||
Single PV array fuse | 16A | |||
Single PV array wire size | PG7、4mm2 | |||
Output data | ||||
Output numbers | 1 | 2 | ||
Max output current | 40A | 30A/each way, total 60A | 40A/each way, total 80A | 50A/each way, total 100A |
Each way output wire size | PG16、each way 8mm2 | PG16、each way 10mm2 | PG16、each way 10mm2 | PG16、each way 12mm |
Max output voltage | 600VDC | |||
DC output circuit breaker | yes | |||
Others data | ||||
protection | IP65 | |||
Temperature range | -30℃ ~ +60℃ | |||
Reference weight(N.W/G.W.) | 5.3/9.3 | 8.4/12.9 | 9.5/14.3 | 10.8/15.6 |
Machine size(D X W X H) | 340*300*140mm | 360*340*145mm | 400*420*145mm | |
Packaging size(D X W X H) | 450*420*245mm | 470*450*255mm | 530*510*255mm | |
Cooling way | Natural cooling | |||
SPD protection | yes | |||
Ground wire size | ≥6mm2 |
